M#52-T19014245
Product Category:Motors/ Transaxles
Product Type:Transaxle assembly
Price:EXW Taiwan Unit Price
Description:
Transaxle Motor (M#52)
      Product Specification

►Code: M#52-T19014245

►Type Number:SC82L244245CRGB0

►Ratio: 1:19

Output Power: 450W

►Motor: DC24V 3.5A(max)

Speed: 4200±150rpm

Transaxle total length:  620.3 mm

►Made in Taiwan

►Standard Type, transaxle with motor and brake

►Sea shipment for large quantity is available

►M#52 Transaxle Assembly Options:

 •19.25:1, 350W, 4350RPM

 •19.25:1, 400W, 4800RPM

 •19:1, 450W, 4200RPM

 •34:1, 750W, 4800RPM

 •20:1, 950W, 4800RPM
